TPED 40 - 530/2 A - F - A - BQQE - MWB

Applicable for
Commercial air - conditioning
Single stage pipeline pump with dual head assembly MGE motor

Grundfos TPED Series Pipeline Circulation Pumps: High - efficiency and Low - energy Consumption, with Variable - frequency Control
The TPED 1000 series and TPE2 D series pipeline circulation pumps are characterized by high efficiency and low - energy consumption. They are equipped with two parallel power heads, providing double reliability, multi - pump functions, and a built - in frequency converter. By connecting external sensors, the pumps can be controlled to optimize the system pressure and flow according to the temperature difference or pressure difference. Due to the close - coupled design, these pumps are less sensitive to impurities in the liquid, and the electroplated layer is corrosion - resistant. This robust and durable vertical pipeline pump is suitable for various applications, including domestic, commercial, and industrial water supply, heating, and cooling systems.

TPED 40 - 530/2 A - F - A - BQQE - MWB A close - coupled single - stage double - head volute pump with coaxial suction and discharge ports of the same diameter. The double - head water pump is designed with two parallel power heads. The water pump features a pull - up design. For example, the power head (motor, pump head, and impeller) can be disassembled for maintenance while the pump casing remains connected to the pipeline. Each power head is equipped with a non - balanced rubber bellows seal. The shaft seal complies with the DIN EN 12756 standard. The pipeline connection is achieved through PN 16 DIN flanges (standards EN 1092 - 2 and ISO 7005 - 2). An air - cooled permanent - magnet synchronous motor of the same size is installed on each variable - frequency head. According to the IEC 60034 - 30 - 2 standard, the energy efficiency of this motor is at the IE5 level.
